Installation and Commissioning
8-18 7SA6 Manual
C53000-G1176-C156-2
Figure 8-9 Front view of device of housing size
1
/
3
after removal of the front cover
(simplified and scaled down)
Slot 5 Slot 19
7SA610∗–∗A/E/J
BI1 to
BI5
7SA610
∗–∗B/F/K
BI6 and
BI7
BI1 to
BI5
1
3
4
Input/output printed circuit board C–I/O–2
Input/output printed circuit board C–I/O–11
Processor printed circuit board C–CPU–2
Binary inputs (BI)
1 3
41
Binary inputs (BI)
