Technical Data
10-22 7SA6 Manual
C53000-G1176-C156
Negative sequence current 3I
2
> 0.05 A to 1.00 A
1
)(steps0.01A)
Negative sequence voltage 3U
2
> 0.5 V to 10.0 V (steps 0.1 V)
“Forward” angle
capacitive Alpha 0° to 360° (steps 1°)
inductive Beta 0° to 360° (steps 1°)
Tolerances pick-up values 10 % of set value
or 5% of nominal current or 0.5 V
“Forward” angle 5°
Re-orientation time after direction change approx. 30 ms
1
) Secondary values based on I
N
=1A;forI
N
= 5 A they must be multiplied by 5.
