Technical Data
10-46 7SA6 Manual
C53000-G1176-C156
Total storage period max. 5 s for each fault
approx. 15 s totally
Sampling rate at f
N
=50Hz 1ms
Sampling rate at f
N
=60Hz 0.83ms
Statistics Number of trip events caused by pole segregated
7SA6
Number of automatic reclosures
initiated by the device separate for 1-pole and 3-pole AR;
separate for 1st AR cycle
and for all further cyles
Total of interrupted currents
caused by 7SA6 pole segregated
Maximum interrupted current pole segregated
Availability of the transmission availability in %/min and %/h
Delay time of transmission resolution 0.01 ms
Real Time Clock
and Buffer Battery
Resolution for operational events 1 ms
Resolution for fault events 1 ms
Buffer battery 3 V/1 Ah, type CR 1/2 AA
self-discharging time approx. 10 years
