Siemens siprotec 7SA6 - Page 716

Technical Data
10-48 7SA6 Manual
C53000-G1176-C156
Housing for Panel
Flush Mounting or
Cubicle Installation
(Size
1
/
2
x 19”)
Figure 10-8 Dimensions 7SA6 for panel flush mounting or cubicle installation (size
1
/
2
x19”)
221
+2
(8.70
+0.08
)
5 (0.20) or M4
6 (0.24)
Panel cut-out
255.8
±
0.3
(10.07
+0.01
)
206.5
± 0.3
(8.13
± 0.01
)
13.2
7.3
5.4
2
29.5
34
Mounting plate
Side view (with screwed terminals)
244 (9.61)
266 (10.47)
2
29.5
34
Mounting plate
29 30
Side view (with plug-in terminals)
Dimensions in mm
(1.16)
172 (6.77)
(1.34)
(0.08)
(1.16)
(1.18)(1.14)
172 (6.77)
266 (10.47)
244 (9.61)
(0.08)
(1.34)
Values in brackets in inches
245
+
1
(9.64
+0.04
)
180
± 0.5
(7.09
± 0.02
)
(0.29)
(0.52)
(0.21)
225 (8.86)
220 (8.66)
Rear view
