Siemens siprotec 7SA6 - Page 722

Technical Data
10-54 7SA6 Manual
C53000-G1176-C156
Housing for
Mounting with
Detached
Operator Panel
(Size
1
/
1
x19”)
Figure 10-15 Dimensions 7SA6 for mounting with detached operator panel (size
1
/
1
x19”)
450 (17.72)
445 (17.52)
Rear View
25
4.5 (0.18)
Mounting Holes of Mounting Plate
300
±
0.3
(11.81
±0.01
)
200
± 0.3
(7.87
±0.01
)
300
± 0.3
(11.81
±0.01
)
400
± 0.3
(15.75
±0.01
)
244 (9.61)
266 (10.47)
209.5 ( 8.25)
Mounting Plate
Side View (with Screw Terminals)
312.8 (12.31)
34 (1.34)
Dimensions in mm
244 (9.61)
266 (10.47)
209.5 (8.25) 29
Mounting Plate
Side View (with Screw Terminals)
30
312.8 (12.31)
34 (1.34)
Values in brackets in inches
(1.14)
(1.18)
6.4 (0.25)
100
± 0.3
(3.94
±0.01
)
