Appendix
A-8 7SA6 Manual
C53000-G1176-C156-2
Region-Specific Default/Language Settings and Function Versions
Region GE, language German (language can be changed) A
Region world, language English (GB) (language can be changed) B
Region US, language English (USA) (language can be changed) C
Region FR, 50 Hz, IEC, French language (may be changed) D
Region World, 50/60 Hz, IEC/ANSI, Spanish language (may be changed) E
Region World, 50/60 Hz, IEC/ANSI, Italian language (may be changed) F
Regulations for Region-Specific Default and Function Settings:
Region World: Preset to f = 50 Hz and line length in km
Region US: Preset to f = 60 Hz and line length in miles, ANSi inverse characteristic only
Region FR: Preset to f = 50 Hz and line length in km, IEC inverse characteristic available,
no STUB-Bus stage available, no logical inverse characteristic for earth fault protection
available
Port B
Not installed 0
System port, IEC protocol, electrical RS232 1
System port, IEC protocol, electrical RS485 2
System port, IEC protocol, optical 820 nm, ST-connector 3
System port, Profibus FMS Slave, electrical RS485 4
System port, Profibus FMS Slave, optical, single-ended ring, ST-connector 5
System port, Profibus FMS Slave, optical, double-ended ring, ST-connector 6
Analog Output 2 x 0 to 20 mA 7
For further protocols see additional information “L” 9
Port B
System port, Profibus DP Slave, electrical RS485 0 A
System port, Profibus DP Slave, optical 820 nm, double-ended ring, ST-connector 0 B
System port, DNP3.0, electrical RS485 0G
System port, DNP3.0, optical 820 nm, double-ended ring, ST-connector 0 H
Port C and Port D
DIGSI/modem, electrical RS232, port C 1
DIGSI/modem, electrical RS485, port C 2
With port C and
D see addtional information “M” 9
Port C
DIGSI/modem, electrical RS232 1
DIGSI/modem, electrical RS485 2
Port D; for 1.) Direct Connection; 2.) Communication Networks
Optical 820 nm, 2-ST-connector, length of optical fibre up to 1.5 km for multimode-fibre (FO5); 1.) or 2.) A
Optical 820 nm, 2-ST-connector, length of optical fibre up to 3.5 km for multimode-fibre (FO6); 1.); B
Optical 1300 nm, 2-ST-connector, length of optical fibre up to 10 km for monomode-fibre (FO7); 1.) C
Optical 1300 nm, 2-FC-connector, length of optical fibre up to 35 km for monomode-fibre (FO8); 1.) D
Analog output
Analog Output 2 x 0 to 20 mA (Port D) K
see page A-8
_
7SA6
7 8 13 15 1614
_
9101112
Distance Protection (position10to12)
6
5
M
+
L+
