Appendix
A-117SA6 Manual
C53000-G1176-C156-2
Plug-in Connectors
Mounting Rail for
19"-Racks
Battery
Interface Cable
An interface cable is necessary for communication between the SIPROTEC device
and a PC. Requirements for the computer are Windows 95 or Windows NT4 and the
operating software DIGSI
®
4
Operating Software
DIGSI
®
4
Software for setting and operating SIPROTEC
®
4 devices
Graphical Analysis
Program SIGRA
Software for graphical visualization, analysis and evaluation of fault data. Option pack-
age of the complete version of DIGSI
®
4
Display Editor Software for creating basic and power system control pictures. Option package
of the complete version of DIGSI
®
4
Graphic Tools Graphical Software to aid in the setting of characteristic curves and provide zone dia-
grams for overcurrent and distance protective devices. Option package of the com-
plete version of DIGSI
®
4.
Connector Type Order No.
2 pin C73334-A1-C35-1
3 pin C73334-A1-C36-1
Name Order No.
Angle Strip (Mounting Rail) C73165-A63-C200-2
Lithium-Battery 3 V/1 Ah, Type CR 1/2 AA Order No.
VARTA 6127 101 501
Interface Cable between PC or SIPROTEC device Order No.
Cable with 9-pin male/female connections 7XV5100-4
Operating Software DIGSI
®
4
Order No.
DIGSI
®
4, basic version with license for 10
computers
7XS5400-0AA00
DIGSI
®
4, complete version with all option packages
7XS5402-0AA0
Graphical Analysis Program SIGRA
®
Order No.
Full version with license for 10 machines 7XS5410-0AA0
Display Editor 4 Order No.
Full version with license for 10 machines 7XS5420-0AA0
Graphic Tools 4 Order No.
Full version with license for 10 machines 7XS5430-0AA0
