Appendix
B-3
7SA6 Manual
C53000-G1176-C156-2
133 Auto Reclose 1 AR-cycle
2 AR-cycles
3 AR-cycles
4 AR-cycles
5 AR-cycles
6 AR-cycles
7 AR-cycles
8 AR-cycles
Adaptive Dead Time
(ADT)
Disabled
Disabled Auto-Reclose Function 133
134 AR control mode with Pickup and
Action time
with Pickup but
without Action time
with Trip and Action
time
with Trip but with-
out Action time
with Trip and Action time Auto-Reclose control mode 134
135 Synchro-Check Disabled
Enabled
Disabled Synchronism and Voltage
Check
135
137 U/O VOLTAGE Disabled
Enabled
Disabled Under / Overvoltage Protec-
tion
137
138 Fault Locator Enabled
Disabled
with BCD-output
Enabled Fault Locator 138
139 BREAKER FAIL-
URE
Disabled
Enabled
Disabled Breaker Failure Protection 139
140 Trip Cir. Sup. Disabled
1tripcircuit
2tripcircuits
3tripcircuits
Disabled Trip Circuit Supervision 140
142 Ther. OVERLOAD Disabled
Enabled
Disabled Thermal overload protection 142
145 P. INTERFACE 1 Enabled
Disabled
Enabled Protection Interface 1 (Port
D)
145
147 NUMBER OF
RELAY
2relays
3relays
2 relays Number of relays 147
150 AnalogOutput B1 Disabled
IL2 [%]
UL23 [%]
|P| [%]
|Q| [%]
Fault location d [%]
Fault location d [km]
Fault location d
[miles]
Trip current Imax
[primary]
Disabled Analog Output B1 (Port B) 150
201 CT Starpoint Power System Data
1
towards Line
towards Busbar
towards Line CT Starpoint
203 Unom PRIMARY Power System Data
1
1.0..1200.0 kV 400.0 kV Rated Primary Voltage
204 Unom SECOND-
ARY
Power System Data
1
80..125 V 100 V Rated Secondary Voltage (L-L)
205 CT PRIMARY Power System Data
1
10..5000 A 1000 A CT Rated Primary Current
206 CT SECONDARY Power System Data
1
1A
5A
1A CT Rated Secondary Current
207 SystemStarpoint Power System Data
1
Solid Earthed
Peterson-Coil earthed
Isolated
Solid Earthed System Starpoint is
Addr. Setting Title Function Setting Options Default Setting Comments
