Siemens siprotec 7SA6 User Manual

Appendix
B-5
7SA6 Manual
C53000-G1176-C156-2
610 FltDisp.LED/LCD Device Display Targets on every
Pickup
Display Targets on TRIP
only
Display Targets on every
Pickup
Fault Display on LED / LCD
615 Spont. FltDisp. Device NO
YES
NO Spontaneous display of flt.annuncia-
tions
1103 FullScaleVolt. Power System Data
2
1.0..1200.0 kV; 0 400.0 kV Measurement: Full Scale Voltage
(100%)
1104 FullScaleCurr. Power System Data
2
10..5000 A 1000 A Measurement: Full Scale Current
(100%)
1105 Line Angle Power System Data
2
30..89 ° 85 ° Line Angle
1110 x' Power System Data
2
0.0050..6.5000 Ohm / km 0.1500 Ohm / km x' - Line Reactance per length unit
1111 Line Length Power System Data
2
1.0..1000.0 km 100.0 km Line Length
1112 x' Power System Data
2
0.0050..10.0000 Ohm / mile 0.2420 Ohm / mile x' - Line Reactance per length unit
1113 Line Length Power System Data
2
0.6..650.0 Miles 62.1 Miles Line Length
1116 RE/RL(Z1) Power System Data
2
-0.33..7.00 1.00 Zero seq. comp. factor RE/RL for Z1
1117 XE/XL(Z1) Power System Data
2
-0.33..7.00 1.00 Zero seq. comp. factor XE/XL for Z1
1118 RE/RL(Z1B...Z5) Power System Data
2
-0.33..7.00 1.00 Zero seq. comp.factor RE/RL for
Z1B...Z5
1119 XE/XL(Z1B...Z5) Power System Data
2
-0.33..7.00 1.00 Zero seq. comp.factor XE/XL for
Z1B...Z5
1120 K0 (Z1) Power System Data
2
0.000..4.000 1.000 Zero seq. comp. factor K0 for zone Z1
1121 Angle K0(Z1) Power System Data
2
-135.00..135.00 ° 0.00 ° Zero seq. comp. angle for zone Z1
1122 K0 (> Z1) Power System Data
2
0.000..4.000 1.000 Zero seq.comp.factor K0,higher zones
>Z1
1123 AngleI K0(> Z1) Power System Data
2
-135.00..135.00 ° 0.00 ° Zero seq. comp. angle, higher zones
>Z1
1126 RM/RL ParalLine Power System Data
2
0.00..8.00 0.00 Mutual Parallel Line comp. ratio RM/
RL
1127 XM/XL ParalLine Power System Data
2
0.00..8.00 0.00 Mutual Parallel Line comp. ratio XM/XL
1128 RATIO Par. Comp Power System Data
2
50..95 % 85 % Neutral current RATIO Parallel Line
Comp
1130A PoleOpenCurrent Power System Data
2
0.05..1.00 A 0.10 A Pole Open Current Threshold
1131A PoleOpenVoltage Power System Data
2
2..70 V 30 V Pole Open Voltage Threshold
1132A SI Time all Cl. Power System Data
2
0.01..30.00 sec 0.05 sec Seal-in Time after ALL closures
1134 Line Closure Power System Data
2
Manual Close BI only
Current OR Voltage or Man-
ual close BI
CBaux OR Current or Man-
ual close BI
Current flow or Manual close
BI
Manual Close BI only Recognition of Line Closures with
1135 Reset Trip CMD Power System Data
2
with Pole Open Current
Threshold only
with CBaux AND Pole Open
Current
with Pole Open Current
Threshold only
RESET of Trip Command
Addr. Setting Title Function Setting Options Default Setting Comments
