Siemens siprotec 7SA6 User Manual

Initial Inspections
3-5
7SA6 Manual
C53000-G1176-C156-2
Figure 3-2 Display of device-specific data — example
Viewing Measured
Values
To view the measured values:
G If the main menu is not shown, press the key. The MAIN MENU appears.
G Usingthe key,selectthemenuitemMeasurement, and move to the measure-
ment values using the key. The MEASUREMENT sub-menu appears.
G Using the key, select the menu item Operation. sec (operating measured
values, secondary), and switch to the OPERATION. SEC sub-menu using the
key.
G Using the and keys, all operating measured values can be viewed.
Since no measured AC voltages or currents are present at this time, all operating
measured values show near zero. Deviations of the last digit are insignificant.
To return to the main menu, press the key once, or repeatedly press the key
or the key.
Viewing Operation-
al Messages
Reading the operational messages is described to serve as an additional example.
G If the main menu is not shown, press the key. The MAIN MENU appears.
G Using the key, select the menu item Annunciation, and switch to the annun-
ciations using the key. The ANNUNCIATION sub-menu appears.
G Usingthe key,selectthemenuitemEvent Log, and move to the EVENT LOG
sub-menu using the key.
The last number in the upper right corner of the display indicates the number of oper-
ational messages stored in memory. The number before the slash indicates the mes-
sage presently being displayed. Upon entering the menu, the latest (newest) message
is shown. The date and time of the event are shown in the display line above the mes-
sage.
G Use the key to read other operational messages.
G Press the key; all LEDs should illuminate. Press the key. The newest mes-
sage in the event log should be “Reset LED”, and the number of messages in
memory should increase by one (maximum of 200).
To return to the main menu, press the key once, or repeatedly press the key
or the key.
MLFB/VERSION 01/03
MLFB: 7SA6...
3HA1
BF–Nr.: 9811049704
SETUP/EXTRAS 05/06
---------------------
Date/Time –> 1
Clock Setup –> 2
Serial Ports –> 3
Device-ID –> 4
>MLFB/Version –> 5
Contrast –> 6
MLFB/VERSION 02/03
Firmware: 4.00.18
Bootsystem: 1.00.04
MENU
MENU ESC
MENU
LED
MENU ESC
