Functions
2.11 Automatic Reclosing System 79
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
181
7153 50N-2 No influence
Starts 79
Stops 79
No influence 50N-2
7154 51 No influence
Starts 79
Stops 79
No influence 51
7155 51N No influence
Starts 79
Stops 79
No influence 51N
7162 sens Ground Flt No influence
Starts 79
Stops 79
No influence (Sensitive) Ground Fault
7163 46 No influence
Starts 79
Stops 79
No influence 46
7164 BINARY INPUT No influence
Starts 79
Stops 79
No influence Binary Input
7165 3Pol.PICKUP BLK YES
NO
NO 3 Pole Pickup blocks 79
7166 50-3 No influence
Starts 79
Stops 79
No influence 50-3
7167 50N-3 No influence
Starts 79
Stops 79
No influence 50N-3
7200 bef.1.Cy:50-1 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50-1
7201 bef.1.Cy:50N-1 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50N-1
7202 bef.1.Cy:50-2 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50-2
7203 bef.1.Cy:50N-2 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 50N-2
7204 bef.1.Cy:51 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 51
7205 bef.1.Cy:51N Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 1. Cycle: 51N
7212 bef.2.Cy:50-1 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 2. Cycle: 50-1
7213 bef.2.Cy:50N-1 Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 2. Cycle: 50N-1
Addr. Parameter Setting Options Default Setting Comments
