2.17.5.4 Information List
2.17.6 Set Points for Measured Values
SIPROTEC devices facilitate the setting of limit values for any measured or metered values. Should any of
these setpoints be reached, exceeded or undershot during operation, the device issues a warning which is in-
dicated in the form of an operational message. This message can be configured to LEDs and/or binary outputs,
transferred via the ports and interconnected in DIGSI CFC. In addition you can use DIGSI CFC to configure set
points for further measured and metered values and allocate these via the DIGSI device matrix. In contrast to
the actual protection functions the limit value monitoring function operates in the background; therefore it may
not pick up if measured values are changed spontaneously in the event of a fault and if protection functions are
picked up. As a message is only issued upon multiple exceeding of the limit values, such limit value monitoring
does not react as fast as the trip signals of protection functions.
Applications
• This monitoring program works with multiple measurement repetitions and lower priority than the protection
functions. For that reason, in the event of a fault it may not respond to fast measured value changes before
protection functions are started and tripped. This monitoring program is not suitable for blocking protection
functions.
No. Information Type of In-
formation
Comments
- ResMinMax IntSP_Ev Reset Minimum and Maximum counter
395 >I MinMax Reset SP >I MIN/MAX Buffer Reset
396 >I1 MiMaReset SP >I1 MIN/MAX Buffer Reset
403 >Idmd MiMaReset SP >Idmd MIN/MAX Buffer Reset
412 > Θ MiMa Reset SP >Theta MIN/MAX Buffer Reset
837 IAdmdMin MVT I A Demand Minimum
838 IAdmdMax MVT I A Demand Maximum
839 IBdmdMin MVT I B Demand Minimum
840 IBdmdMax MVT I B Demand Maximum
841 ICdmdMin MVT I C Demand Minimum
842 ICdmdMax MVT I C Demand Maximum
843 I1dmdMin MVT I1 (positive sequence) Demand Minimum
844 I1dmdMax MVT I1 (positive sequence) Demand Maximum
851 Ia Min= MVT Ia Min
852 Ia Max= MVT Ia Max
853 Ib Min= MVT Ib Min
854 Ib Max= MVT Ib Max
855 Ic Min= MVT Ic Min
856 Ic Max= MVT Ic Max
857 I1 Min= MVT I1 (positive sequence) Minimum
858 I1 Max= MVT I1 (positive sequence) Maximum
1058 Θ/ΘTrpMax= MVT Overload Meter Max
1059 Θ/ΘTrpMin= MVT Overload Meter Min
