Siemens SIPROTEC 7SJ61 - Certifications; Design

Technical Data
4.1 General Device Data
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
317
4.1.9 Certifications
4.1.10 Design
UL listing UL recognition
7SJ61**-*B***-**** Models with threaded ter-
minals
7SJ61**-*D***-**** Models with
plug-in terminals
7SJ61**-*E***-****
Housing 7XP20
Dimensions See dimensional drawings, Section 4.22
Weight (mass) approx.
— Housing for panel surface mounting 9.9 lb or 4.5 kg
— Housing for panel surface mounting 8.8 lb or 4.0 kg
Protection class acc. to IEC 60529
For surface mounting housing equipment IP 51
In flush mounted housing
Front IP 51
Rear IP 50
For personal protection IP 2x with cover cap
UL conditions “For use on a Flat Surface of a Type 1 Enclosure”
