2.2.7 Pickup Logic and Tripping Logic
The pickup annunciations of the individual phases (or ground) and the individual elements are combined with
each other in such a way that the phase information and the element that has picked up are issued.
Table 2-2 Pickup annunciations of the overcurrent protection
In the trip signals, the element which initiated the tripping is also indicated.
Internal Annunciation Display Output Annunciation FNo.
50-3 A PU
50-2 A PU
50-1 A PU
51 A PU
2-4
2-6
2-10
„50/51 Ph A PU“ 1762
50-3 B PU
50-2 B PU
50-1 B PU
51 B PU
2-4
2-6
2-10
„50/51 Ph B PU“ 1763
50-3 C PU
50-2 C PU
50-1 C PU
51 C PU
2-4
2-6
2-10
„50/51 Ph C PU“ 1764
50N-3 PU
50N-2 PU
50N-1 PU
51N PU
2-5
2-8
2-11
„50N/51NPickedup“ 1765
50-3 A PU
50-3 B PU
50-3 C PU
50N-3 PU
„50-3 picked up“ 1767
50-2 A PU
50-2 B PU
50-2 C PU
50N-2 PU
2-4
2-4
2-4
2-5
„50-2 picked up“ 1800
50-1 C PU
50-1 B PU
50-1 A PU
50N-1 PU
2-6
2-6
2-6
2-5
„50-1 picked up“ 1810
51 PU A
51 PU B
51 PU C
51N PU
2-10
2-10
2-10
2-11
„51 picked up“ 1820
(All pickups) „50(N)/51(N) PU“ 1761
