Appendix
A.1 Ordering Information and Accessories
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
370
A.1 Ordering Information and Accessories
A.1.1 Ordering Information
A.1.1.1 7SJ61 V4.7
Multi-Functional Pro-
tection with Control
6 7 8 9 10 11 12 13 14 15 16 Supplemen-
tary
7SJ61 ––+
Number of Binary Inputs and Outputs Position
6
3 Binary Inputs, 4 Binary Outputs, 1 Live Status Contact 0
8 Binary Inputs, 8 Binary Outputs, 1 Live Status Contact 1
11 Binary Inputs, 6 Binary Outputs, 1 Live Status Contact 2
Nominal current Position
7
I
ph
= 1 A, I
N
= 1 A (min. = 0.05 A); 15th position only with A 1
I
ph
= 1 A, I
N
= sensitive (min. = 0.001 A); 15th position only with B 2
I
ph
= 5 A, I
N
= 5 A (min. = 0.25 A); 15th position only with A 5
I
ph
= 5 A, I
N
= sensitive (min. = 0.001 A); 15th position only with B 6
I
ph
= 5 A, I
N
= 1 A (min. = 0.05 A); 15th position only with A 7
Auxiliary Voltage (Power Supply, Pickup Threshold of Binary Inputs) Position
8
24 to 48 VDC, Binary Input Threshold 19 VDC 2
60 to 125 VDC, Binary Input Threshold 19 VDC 4
110 to 250 VDC, 115 to 230 VAC, Binary Input Threshold 88 VDC 5
Construction Position
9
Surface-mounting case for panel, 2 tier terminals top/bottom B
Flush mounting case, plug-in terminals (2/3-pole connector) D
Flush mounting case, screw-type terminals (direct connection / ring lugs) E
Region-specific default / language settings and function versions Position
10
Region DE, 50 Hz, IEC, German Language (Language can be changed) A
Region World, 50/60 Hz, IEC/ANSI, Language English (Language can be changed) B
Region US, 60/50 Hz, ANSI, Language American English (Language can be changed) C
Region FR, 50/60 Hz, IEC/ANSI, Language French (Language can be changed) D
Region World, 50/60 Hz, IEC/ANSI, Language Spanish (Language can be changed) E
Region IT, 50/60 Hz, IEC/ANSI, Language Italian (Language can be changed) F
