Siemens SIPROTEC 7SJ61 - Measured Values

Appendix
A.11 Measured Values
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
434
A.11 Measured Values
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
- I A dmd> (I Admd>) Set Points(MV) - - - - - CFC CD DD
- I B dmd> (I Bdmd>) Set Points(MV) - - - - - CFC CD DD
- I C dmd> (I Cdmd>) Set Points(MV) - - - - - CFC CD DD
- I1dmd> (I1dmd>) Set Points(MV) - - - - - CFC CD DD
- 37-1 under current (37-1) Set Points(MV) - - - - - CFC CD DD
- Number of TRIPs= (#of TRIPs=) Statistics - - - - - CFC CD DD
- Operating hours greater than (OpHour>) SetPoint(Stat) - - - - - CFC CD DD
601 Ia (Ia =) Measurement 134 137 No 9 1 CFC CD DD
602 Ib (Ib =) Measurement 160 144 Yes 3 1 CFC CD DD
134 137 No 9 2
603 Ic (Ic =) Measurement 134 137 No 9 3 CFC CD DD
604 In (In =) Measurement 134 137 No 9 4 CFC CD DD
605 I1 (positive sequence) (I1 =) Measurement - - - - - CFC CD DD
606 I2 (negative sequence) (I2 =) Measurement - - - - - CFC CD DD
661 Threshold of Restart Inhibit (Θ REST. =) Measurement - - - - - CFC CD DD
805 Temperature of Rotor (Θ Rotor) Measurement - - - - - CFC CD DD
807 Thermal Overload (Θ/Θtrip) Measurement - - - - - CFC CD DD
809 Time untill release of reclose-blocking (T re-
close=)
Measurement - - - - - CFC CD DD
830 INs Senstive Ground Fault Current (INs =) Measurement - - - - - CFC CD DD
831 3Io (zero sequence) (3Io =) Measurement - - - - - CFC CD DD
833 I1 (positive sequence) Demand (I1 dmd=) Demand meter - - - - - CFC CD DD
837 I A Demand Minimum (IAdmdMin) Min/Max meter - - - - - CFC CD DD
838 I A Demand Maximum (IAdmdMax) Min/Max meter - - - - - CFC CD DD
839 I B Demand Minimum (IBdmdMin) Min/Max meter - - - - - CFC CD DD
840 I B Demand Maximum (IBdmdMax) Min/Max meter - - - - - CFC CD DD
841 I C Demand Minimum (ICdmdMin) Min/Max meter - - - - - CFC CD DD
842 I C Demand Maximum (ICdmdMax) Min/Max meter - - - - - CFC CD DD
843 I1 (positive sequence) Demand Minimum
(I1dmdMin)
Min/Max meter - - - - - CFC CD DD
844 I1 (positive sequence) Demand Maximum
(I1dmdMax)
Min/Max meter - - - - - CFC CD DD
851 Ia Min (Ia Min=) Min/Max meter - - - - - CFC CD DD
852 Ia Max (Ia Max=) Min/Max meter - - - - - CFC CD DD
853 Ib Min (Ib Min=) Min/Max meter - - - - - CFC CD DD
854 Ib Max (Ib Max=) Min/Max meter - - - - - CFC CD DD
855 Ic Min (Ic Min=) Min/Max meter - - - - - CFC CD DD
856 Ic Max (Ic Max=) Min/Max meter - - - - - CFC CD DD
857 I1 (positive sequence) Minimum (I1 Min=) Min/Max meter - - - - - CFC CD DD
858 I1 (positive sequence) Maximum (I1 Max=) Min/Max meter - - - - - CFC CD DD
888 Pulsed Energy Wp (active) (Wp(puls)) Energy 133 55 No 205 - CFC CD DD
889 Pulsed Energy Wq (reactive) (Wq(puls)) Energy 133 56 No 205 - CFC CD DD
963 I A demand (Ia dmd=) Demand meter - - - - - CFC CD DD
964 I B demand (Ib dmd=) Demand meter - - - - - CFC CD DD
965 I C demand (Ic dmd=) Demand meter - - - - - CFC CD DD
