Appendix
A.7 Functional Scope
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
400
A.7 Functional Scope
Addr. Parameter Setting Options Default Setting Comments
103 Grp Chge OPTION Disabled
Enabled
Disabled Setting Group Change Option
104 OSC. FAULT REC. Disabled
Enabled
Enabled Oscillographic Fault Records
112 Charac. Phase Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Definite Time 50/51
113 Charac. Ground Disabled
Definite Time
TOC IEC
TOC ANSI
User Defined PU
User def. Reset
Definite Time 50N/51N
117 Coldload Pickup Disabled
Enabled
Disabled Cold Load Pickup
122 InrushRestraint Disabled
Enabled
Disabled 2nd Harmonic Inrush Restraint
127 50 1Ph Disabled
Enabled
Disabled 50 1Ph
131 Sens. Gnd Fault Disabled
Definite Time
User Defined PU
Log. inverse A
Log. Inverse B
Disabled (sensitive) Ground fault
133 INTERM.EF Disabled
with Ignd
with 3I0
with Ignd,sens.
Disabled Intermittent earth fault protection
140 46 Disabled
TOC ANSI
TOC IEC
Definite Time
Disabled 46 Negative Sequence Protection
141 48 Disabled
Enabled
Disabled 48 Startup Supervision of Motors
142 49 Disabled
No ambient temp
With amb. temp.
Disabled 49 Thermal Overload Protection
143 66 #of Starts Disabled
Enabled
Disabled 66 Startup Counter for Motors
144 LOAD JAM PROT. Disabled
Enabled
Disabled Load Jam Protection
170 50BF Disabled
Enabled
enabled w/ 3I0>
Disabled 50BF Breaker Failure Protection
171 79 Auto Recl. Disabled
Enabled
Disabled 79 Auto-Reclose Function
