4.7 Negative Sequence Protection 46-1, 46-2
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
334
4.7 Negative Sequence Protection 46-1, 46-2
Setting Ranges / Increments
Functional Limit
Times
Dropout Ratio
Tolerances
Influencing Variables for Pickup Values
Unbalanced load tripping element
46-1,46-2
for I
Nom
= 1 A 0.10 A to 3.00 A or ∞ (disabled) Increments 0.01 A
for I
Nom
= 5 A 0.50 A to 15.00 A or ∞ (disabled)
Delay Times 46-1, 46-2 0.00 s to 60.00 s or ∞ (disabled) Increments 0.01 s
Dropout Delay Times 46 T DROP-OUT 0.00 s to 60.00 s Increments 0.01 s
Functional Limit for I
Nom
= 1 A all phase currents ≤ 10 A
for I
Nom
= 5 A all phase currents ≤ 50 A
Pickup Times
Dropout Times
Approx. 35 ms
Approx. 35 ms
Characteristic 46-1, 46-2 Approx. 0.95 for I
2
/I
Nom
≥ 0.3
Pickup values 46-1, 46-2 3 % of set value or 10 mA for I
Nom
= 1 A or 50 mA for I
Nom
= 5 A
Time Delays 1 % or 10 ms
Power supply direct voltage in range 0.8 ≤ V
PS
/V
PSNom
≤ 1.15 1 %
Temperature in range 23.00 °F (-5 °C) ≤ Θ
amb
≤ 131.00 °F (55 °C) 0.5 %/10 K
Frequency in range 0.95 ≤ f/f
Nom
≤ 1.05 1 %
Harmonics
- up to 10 % 3rd harmonic
- up to 10 % 5th harmonic
1%
1%
Transient overreaction for τ > 100 ms (with full displacement) <5 %
