Appendix
A.5 Default Settings
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
394
A.5 Default Settings
When the device leaves the factory, a large number of LED indications, binary inputs and outputs as well as
function keys are already preset. They are summarised in the following table.
A.5.1 LEDs
Table A-3 Preset LED displays
A.5.2 Binary Input
Table A-4 Binary input presettings for all devices and ordering variants
Table A-5 Further binary input presettings for 7SJ611*- and 7SJ612*-
LEDs Default function Function No. Description
LED1 Relay TRIP 511 Relay GENERAL TRIP command
LED2 50/51 Ph A PU 1762 50/51 Phase A picked up
LED3 50/51 Ph B PU 1763 50/51 Phase B picked up
LED4 50/51 Ph C PU 1764 50/51 Phase C picked up
LED5 50N/51NPickedup 1765 50N/51N picked up
LED6 Failure Σ I 162 Failure: Current Summation
Fail I balance 163 Failure: Current Balance
Fail Ph. Seq. I 175 Failure: Phase Sequence Current
LED7 Not configured 1 No Function configured
Binary Input Default function Function No. Description
BI1 >BLOCK 50-2 1721 >BLOCK 50-2
>BLOCK 50N-2 1724 >BLOCK 50N-2
BI2 >Reset LED 5 >Reset LED
BI3 >Light on >Back Light on
Binary Input Default function Function No. Description
BI4 >52-b 4602 >52-b contact (OPEN, if bkr is closed)
52Breaker 52 Breaker
BI5 >52-a 4601 >52-a contact (OPEN, if bkr is open)
52Breaker 52 Breaker
