A.5.3 Binary Output
Table A-6 Output Relay Presettings for All Devices and Ordering Variants
Table A-7 Further Output Relay Presettings for 7SJ611**-, 7SJ612**-
A.5.4 Function Keys
Table A-8 Applies to All Devices and Ordered Variants
Binary Output Default function Function No. Description
BO1 Relay TRIP 511 Relay GENERAL TRIP command
52Breaker 52 Breaker
BO2 52Breaker 52 Breaker
79 Close 2851 79 - Close command
BO3 52Breaker 52 Breaker
79 Close 2851 79 - Close command
BO4 Failure Σ I 162 Failure: Current Summation
Fail I balance 163 Failure: Current Balance
Fail Ph. Seq. I 175 Failure: Phase Sequence Current
Binary Output Default function Function No. Description
BO7 Relay PICKUP 501 Relay PICKUP
Function Keys Default function
F1 Display of operational indications
F2 Display of the primary operational measured values
F3 Display of the last fault event recording
F4 Not preassigned
