Technical Data
4.1 General Device Data
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
307
Alternating Voltage
4.1.3 Binary Inputs and Outputs
Binary Inputs
Voltage supply using integrated converter
Rated auxiliary AC V
Aux
115VAC 230VAC
Permissible Voltage Ranges 92 to 132 VAC 184 to 265 VAC
Power consumption, quiescent Approx. 3 VA Approx. 3 VA
Power consumption, energized Approx. 7 VA Approx. 7 VA
Bridging time for failure/short circuit (in not ener-
gized operation)
≥ 200 ms
Variant Quantity
7SJ610*– 3 (configurable)
7SJ611*– 8 (configurable)
7SJ612*– 11 (configurable)
Rated Voltage Range 24 VDC to 250 VDC, bipolar
Current Consumption (independent of the control
voltage)
Approx. 1.8 mA
Pickup time Approx. 4 ms
Switching Thresholds Switching Thresholds, adjustable voltage range with
jumpers
For Nominal Voltages 24/48/60/110/125 VDC V high ≥ 19 VDC
V low ≤ 10 VDC
For Nominal Voltages 110/125/220/250 VDC V high ≥ 88 VDC
V low ≤ 44VDC
for nominal voltages (only for modules with 3
switching thresholds)
220/250 VDC and 115/230
VAC
V high ≤ 176 VDC
V low ≤ 88 VDC
Maximum admissible voltage 300 VDC
Impulse Filter on Input 220 nF Coupling Capacitor at 220 V with recovery time >
60 ms
