Appendix
A.11 Measured Values
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
435
■
1058 Overload Meter Max (Θ/ΘTrpMax=) Min/Max meter - - - - - CFC CD DD
1059 Overload Meter Min (Θ/ΘTrpMin=) Min/Max meter - - - - - CFC CD DD
1068 Temperature of RTD 1 (Θ RTD 1 =) Measurement 134 146 No 9 1 CFC CD DD
1069 Temperature of RTD 2 (Θ RTD 2 =) Measurement 134 146 No 9 2 CFC CD DD
1070 Temperature of RTD 3 (Θ RTD 3 =) Measurement 134 146 No 9 3 CFC CD DD
1071 Temperature of RTD 4 (Θ RTD 4 =) Measurement 134 146 No 9 4 CFC CD DD
1072 Temperature of RTD 5 (Θ RTD 5 =) Measurement 134 146 No 9 5 CFC CD DD
1073 Temperature of RTD 6 (Θ RTD 6 =) Measurement 134 146 No 9 6 CFC CD DD
1074 Temperature of RTD 7 (Θ RTD 7 =) Measurement 134 146 No 9 7 CFC CD DD
1075 Temperature of RTD 8 (Θ RTD 8 =) Measurement 134 146 No 9 8 CFC CD DD
1076 Temperature of RTD 9 (Θ RTD 9 =) Measurement 134 146 No 9 9 CFC CD DD
1077 Temperature of RTD10 (Θ RTD10 =) Measurement 134 146 No 9 10 CFC CD DD
1078 Temperature of RTD11 (Θ RTD11 =) Measurement 134 146 No 9 11 CFC CD DD
1079 Temperature of RTD12 (Θ RTD12 =) Measurement 134 146 No 9 12 CFC CD DD
16004 Threshold Sum Current Exponentiation
(ΣI^x>)
SetPoint(Stat) - - - - - CFC CD DD
16009 Lower Threshold of CB Residual Endurance
(Resid.Endu. <)
SetPoint(Stat) - - - - - CFC CD DD
16017 Threshold Sum Squared Current Integral
(ΣI^2t>)
SetPoint(Stat) - - - - - CFC CD DD
16032 In2 (In2 =) Measurement - - - - - CFC CD DD
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
