Functions
2.14 Temperature Detection via RTD Boxes
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
205
9063 RTD 6 STAGE 1 -50 .. 250 °C; ∞ 100 °C RTD 6: Temperature Stage 1
Pickup
9064 RTD 6 STAGE 1 -58 .. 482 °F; ∞ 212 °F RTD 6: Temperature Stage 1
Pickup
9065 RTD 6 STAGE 2 -50 .. 250 °C; ∞ 120 °C RTD 6: Temperature Stage 2
Pickup
9066 RTD 6 STAGE 2 -58 .. 482 °F; ∞ 248 °F RTD 6: Temperature Stage 2
Pickup
9071A RTD 7 TYPE Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Not connected RTD 7: Type
9072A RTD 7 LOCATION Oil
Ambient
Winding
Bearing
Other
Other RTD 7: Location
9073 RTD 7 STAGE 1 -50 .. 250 °C; ∞ 100 °C RTD 7: Temperature Stage 1
Pickup
9074 RTD 7 STAGE 1 -58 .. 482 °F; ∞ 212 °F RTD 7: Temperature Stage 1
Pickup
9075 RTD 7 STAGE 2 -50 .. 250 °C; ∞ 120 °C RTD 7: Temperature Stage 2
Pickup
9076 RTD 7 STAGE 2 -58 .. 482 °F; ∞ 248 °F RTD 7: Temperature Stage 2
Pickup
9081A RTD 8 TYPE Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Not connected RTD 8: Type
9082A RTD 8 LOCATION Oil
Ambient
Winding
Bearing
Other
Other RTD 8: Location
9083 RTD 8 STAGE 1 -50 .. 250 °C; ∞ 100 °C RTD 8: Temperature Stage 1
Pickup
9084 RTD 8 STAGE 1 -58 .. 482 °F; ∞ 212 °F RTD 8: Temperature Stage 1
Pickup
9085 RTD 8 STAGE 2 -50 .. 250 °C; ∞ 120 °C RTD 8: Temperature Stage 2
Pickup
9086 RTD 8 STAGE 2 -58 .. 482 °F; ∞ 248 °F RTD 8: Temperature Stage 2
Pickup
9091A RTD 9 TYPE Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Not connected RTD 9: Type
Addr. Parameter Setting Options Default Setting Comments
