Siemens SIPROTEC 7SJ61 User Manual

Functions
2.1 General
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
31
140 46 Disabled
TOC ANSI
TOC IEC
Definite Time
Disabled 46 Negative Sequence Protection
141 48 Disabled
Enabled
Disabled 48 Startup Supervision of Motors
142 49 Disabled
No ambient temp
With amb. temp.
Disabled 49 Thermal Overload Protection
143 66 #of Starts Disabled
Enabled
Disabled 66 Startup Counter for Motors
144 LOAD JAM PROT. Disabled
Enabled
Disabled Load Jam Protection
170 50BF Disabled
Enabled
enabled w/ 3I0>
Disabled 50BF Breaker Failure Protection
171 79 Auto Recl. Disabled
Enabled
Disabled 79 Auto-Reclose Function
172 52 B.WEAR MONIT Disabled
Ix-Method
2P-Method
I2t-Method
Disabled 52 Breaker Wear Monitoring
182 74 Trip Ct Supv Disabled
2 Binary Inputs
1 Binary Input
Disabled 74TC Trip Circuit Supervision
190 RTD-BOX INPUT Disabled
Port C
Disabled External Temperature Input
191 RTD CONNECTION 6 RTD simplex
6 RTD HDX
12 RTD HDX
6 RTD simplex Ext. Temperature Input Connec-
tion Type
- FLEXIBLE FUNC. 1..20 Flex. Function 01
Flex. Function 02
Flex. Function 03
Flex. Function 04
Flex. Function 05
Flex. Function 06
Flex. Function 07
Flex. Function 08
Flex. Function 09
Flex. Function 10
Flex. Function 11
Flex. Function 12
Flex. Function 13
Flex. Function 14
Flex. Function 15
Flex. Function 16
Flex. Function 17
Flex. Function 18
Flex. Function 19
Flex. Function 20
Please select Flexible Functions
Addr. Parameter Setting Options Default Setting Comments
