A.8 Settings
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
403
235A ATEX100 P.System Data 1 NO
YES
NO Storage of th. Replicas w/o
Power Supply
238 Ignd2-CT PRIM P.System Data 1 1 .. 50000 A 60 A Ignd2-CT rated primary c. (conn.
to I2)
250A 50/51 2-ph prot P.System Data 1 ON
OFF
OFF 50, 51 Time Overcurrent with
2ph. prot.
251A CT Connect. P.System Data 1 A, B, C, (Gnd)
A,G2,C,G; G->B
A,G2,C,G; G2->B
A, B, C, (Gnd) CT Connection
260 Ir-52 P.System Data 1 10 .. 50000 A 125 A Rated Normal Current (52 Break-
er)
261 OP.CYCLES AT Ir P.System Data 1 100 .. 1000000 10000 Switching Cycles at Rated
Normal Current
262 Isc-52 P.System Data 1 10 .. 100000 A 25000 A Rated Short-Circuit Breaking
Current
263 OP.CYCLES Isc P.System Data 1 1 .. 1000 50 Switch. Cycles at Rated Short-
Cir. Curr.
264 Ix EXPONENT P.System Data 1 1.0 .. 3.0 2.0 Exponent for the Ix-Method
265 Cmd.via control P.System Data 1 (Setting options depend
on configuration)
None 52 B.Wear: Open Cmd. via
Control Device
266 T 52 BREAKTIME P.System Data 1 1 .. 600 ms 80 ms Breaktime (52 Breaker)
267 T 52 OPENING P.System Data 1 1 .. 500 ms 65 ms Opening Time (52 Breaker)
276 TEMP. UNIT P.System Data 1 Celsius
Fahrenheit
Celsius Unit of temperature measure-
ment
280 Holmgr. for Σi P.System Data 1 NO
YES
NO Holmgreen-conn. (for fast sum-i-
monit.)
302 CHANGE Change Group Group A
Group B
Group C
Group D
Binary Input
Protocol
Group A Change to Another Setting
Group
401 WAVEFORMTRIGGER Osc. Fault Rec. Save w. Pickup
Save w. TRIP
Start w. TRIP
Save w. Pickup Waveform Capture
402 WAVEFORM DATA Osc. Fault Rec. Fault event
Pow.Sys.Flt.
Fault event Scope of Waveform Data
403 MAX. LENGTH Osc. Fault Rec. 0.30 .. 5.00 sec 2.00 sec Max. length of a Waveform
Capture Record
404 PRE. TRIG. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.25 sec Captured Waveform Prior to
Trigger
405 POST REC. TIME Osc. Fault Rec. 0.05 .. 0.50 sec 0.10 sec Captured Waveform after Event
406 BinIn CAPT.TIME Osc. Fault Rec. 0.10 .. 5.00 sec; ∞ 0.50 sec Capture Time via Binary Input
610 FltDisp.LED/LCD Device, General Target on PU
Target on TRIP
Target on PU Fault Display on LED / LCD
613A 50N/51N/67N w. P.System Data 1 Ignd (measured)
3I0 (calcul.)
Ignd (measured) 50N/51N/67N Ground Overcur-
rent with
640 Start image DD Device, General image 1
image 2
image 3
image 4
image 1 Start image Default Display
1102 FullScaleCurr. P.System Data 2 10 .. 50000 A 100 A Measurem:FullScaleCur-
rent(Equipm.rating)
1107 I MOTOR START P.System Data 2 1A 0.40 .. 10.00 A 2.50 A Motor Start Current (Block 49,
Start 48)
5A 2.00 .. 50.00 A 12.50 A
1201 FCT 50/51 50/51 Overcur. ON
OFF
ON 50, 51 Phase Time Overcurrent
1202 50-2 PICKUP 50/51 Overcur. 1A 0.10 .. 35.00 A; ∞ 2.00 A 50-2 Pickup
5A 0.50 .. 175.00 A; ∞ 10.00 A
1203 50-2 DELAY 50/51 Overcur. 0.00 .. 60.00 sec; ∞ 0.00 sec 50-2 Time Delay
1204 50-1 PICKUP 50/51 Overcur. 1A 0.10 .. 35.00 A; ∞ 1.00 A 50-1 Pickup
5A 0.50 .. 175.00 A; ∞ 5.00 A
1205 50-1 DELAY 50/51 Overcur. 0.00 .. 60.00 sec; ∞ 0.50 sec 50-1 Time Delay
Addr. Parameter Function C Setting Options Default Setting Comments
