Siemens SIPROTEC 7SJ61 - Page 411

Appendix
A.8 Settings
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
411
7255 bef.4.Cy:50N-3 79M Auto Recl. Set value T=T
instant. T=0
blocked T=∞
Set value T=T before 4. Cycle: 50N-3
8101 MEASURE. SUPERV Measurem.Superv OFF
ON
ON Measurement Supervision
8104 BALANCE I LIMIT Measurem.Superv 1A 0.10 .. 1.00 A 0.50 A Current Threshold for Balance
Monitoring
5A 0.50 .. 5.00 A 2.50 A
8105 BAL. FACTOR I Measurem.Superv 0.10 .. 0.90 0.50 Balance Factor for Current
Monitor
8106 Σ I THRESHOLD Measurem.Superv 1A 0.05 .. 2.00 A; ∞ 0.10 A Summated Current Monitoring
Threshold
5A 0.25 .. 10.00 A; ∞ 0.50 A
8107 Σ I FACTOR Measurem.Superv 0.00 .. 0.95 0.10 Summated Current Monitoring
Factor
8109 FAST Σ i MONIT Measurem.Superv OFF
ON
ON Fast Summated Current Monitor-
ing
8201 FCT 74TC 74TC TripCirc. ON
OFF
ON 74TC TRIP Circuit Supervision
8202 Alarm Delay 74TC TripCirc. 1 .. 30 sec 2 sec Delay Time for alarm
8301 DMD Interval Demand meter 15 Min., 1 Sub
15 Min., 3 Subs
15 Min.,15 Subs
30 Min., 1 Sub
60 Min., 1 Sub
60 Min.,10 Subs
5 Min., 5 Subs
60 Min., 1 Sub Demand Calculation Intervals
8302 DMD Sync.Time Demand meter On The Hour
15 After Hour
30 After Hour
45 After Hour
On The Hour Demand Synchronization Time
8311 MinMax cycRESET Min/Max meter NO
YES
YES Automatic Cyclic Reset Function
8312 MiMa RESET TIME Min/Max meter 0 .. 1439 min 0 min MinMax Reset Timer
8313 MiMa RESETCYCLE Min/Max meter 1 .. 365 Days 7 Days MinMax Reset Cycle Period
8314 MinMaxRES.START Min/Max meter 1 .. 365 Days 1 Days MinMax Start Reset Cycle in
8315 MeterResolution Energy Standard
Factor 10
Factor 100
Standard Meter resolution
9011A RTD 1 TYPE RTD-Box Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Pt 100 Ω RTD 1: Type
9012A RTD 1 LOCATION RTD-Box Oil
Ambient
Winding
Bearing
Other
Oil RTD 1: Location
9013 RTD 1 STAGE 1 RTD-Box -50 .. 250 °C; ∞ 100 °C RTD 1: Temperature Stage 1
Pickup
9014 RTD 1 STAGE 1 RTD-Box -58 .. 482 °F; ∞ 212 °F RTD 1: Temperature Stage 1
Pickup
9015 RTD 1 STAGE 2 RTD-Box -50 .. 250 °C; ∞ 120 °C RTD 1: Temperature Stage 2
Pickup
9016 RTD 1 STAGE 2 RTD-Box -58 .. 482 °F; ∞ 248 °F RTD 1: Temperature Stage 2
Pickup
9021A RTD 2 TYPE RTD-Box Not connected
Pt 100 Ω
Ni 120 Ω
Ni 100 Ω
Not connected RTD 2: Type
9022A RTD 2 LOCATION RTD-Box Oil
Ambient
Winding
Bearing
Other
Other RTD 2: Location
9023 RTD 2 STAGE 1 RTD-Box -50 .. 250 °C; ∞ 100 °C RTD 2: Temperature Stage 1
P
ickup
9024 RTD 2 STAGE 1 RTD-Box -58 .. 482 °F; ∞ 212 °F RTD 2: Temperature Stage 1
Pickup
Addr. Parameter Function C Setting Options Default Setting Comments
