Appendix
A.9 Information List
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
416
- Setting Group C is active
(GroupC act)
Change Group IntSP On
Off
* * LED BO 160 25 1 Yes
- Setting Group D is active
(GroupD act)
Change Group IntSP On
Off
* * LED BO 160 26 1 Yes
- Controlmode REMOTE (ModeR-
EMOTE)
Cntrl Authority IntSP On
Off
* LED BO
- Control Authority (Cntrl Auth) Cntrl Authority IntSP On
Off
* LED BO 101 85 1 Yes
- Controlmode LOCAL (ModeLO-
CAL)
Cntrl Authority IntSP On
Off
* LED BO 101 86 1 Yes
- 52 Breaker (52Breaker) Control Device CF_D
12
On
Off
LED BO 240 160 20
- 52 Breaker (52Breaker) Control Device DP On
Off
BI CB 240 160 1 Yes
- Disconnect Switch (Disc.Swit.) Control Device CF_D
2
On
Off
LED BO 240 161 20
- Disconnect Switch (Disc.Swit.) Control Device DP On
Off
BI CB 240 161 1 Yes
- Ground Switch (GndSwit.) Control Device CF_D
2
On
Off
LED BO 240 164 20
- Ground Switch (GndSwit.) Control Device DP On
Off
BI CB 240 164 1 Yes
- Interlocking: 52 Open (52 Open) Control Device IntSP * LED BO
- Interlocking: 52 Close (52 Close) Control Device IntSP * LED BO
- Interlocking: Disconnect switch
Open (Disc.Open)
Control Device IntSP * LED BO
- Interlocking: Disconnect switch
Close (Disc.Close)
Control Device IntSP * LED BO
- Interlocking: Ground switch Open
(GndSw Open)
Control Device IntSP * LED BO
- Interlocking: Ground switch Close
(GndSw Cl.)
Control Device IntSP * LED BO
- Unlock data transmission via BI
(UnlockDT)
Control Device IntSP * LED BO
- Q2 Open/Close (Q2 Op/Cl) Control Device CF_D
2
On
Off
LED BO 240 162 20
- Q2 Open/Close (Q2 Op/Cl) Control Device DP On
Off
BI CB 240 162 1 Yes
- Q9 Open/Close (Q9 Op/Cl) Control Device CF_D
2
On
Off
LED BO 240 163 20
- Q9 Open/Close (Q9 Op/Cl) Control Device DP On
Off
BI CB 240 163 1 Yes
- Fan ON/OFF (Fan ON/OFF) Control Device CF_D
2
On
Off
LED BO 240 175 20
- Fan ON/OFF (Fan ON/OFF) Control Device DP On
Off
BI CB 240 175 1 Yes
- >CB ready Spring is charged
(>CB ready)
Process Data SP * * * LED BI BO CB
- >Door closed (>DoorClose) Process Data SP * * * LED BI BO CB
- >Cabinet door open (>Door
open)
Process Data SP On
Off
**LEDBIBOCB10111Yes
- >CB waiting for Spring charged
(>CB wait)
Process Data SP On
Off
**
LEDBIBOCB10121Yes
- >No Voltage (Fuse blown) (>No
Volt.)
Process Data SP On
Off
* * LED BI BO CB 160 38 1 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
