Appendix
A.9 Information List
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
418
71 Settings Check (Settings Check) Device, General OUT * * * LED BO
72 Level-2 change (Level-2 change) Device, General OUT On
Off
**LEDBO
73 Local setting change (Local
change)
Device, General OUT * * *
110 Event lost (Event Lost) Device, General OUT_
Ev
on * LED BO 135 130 1 No
113 Flag Lost (Flag Lost) Device, General OUT on * m LED BO 135 136 1 Yes
125 Chatter ON (Chatter ON) Device, General OUT On
Off
* * LED BO 135 145 1 Yes
126 Protection ON/OFF (via system
port) (ProtON/OFF)
P.System Data 2 IntSP On
Off
**LEDBO
127 79 ON/OFF (via system port) (79
ON/OFF)
79M Auto Recl. IntSP On
Off
**LEDBO
140 Error with a summary alarm
(Error Sum Alarm)
Device, General OUT On
Off
* * LED BO 160 47 1 Yes
144 Error 5V (Error 5V) Device, General OUT On
Off
**LEDBO
145 Error 0V (Error 0V) Device, General OUT On
Off
**LEDBO
146 Error -5V (Error -5V) Device, General OUT On
Off
**LEDBO
147 Error Power Supply (Error Pwr-
Supply)
Device, General OUT On
Off
**LEDBO
160 Alarm Summary Event (Alarm
Sum Event)
Device, General OUT On
Off
* * LED BO 160 46 1 Yes
161 Failure: General Current Supervi-
sion (Fail I Superv.)
Measurem.Superv OUT On
Off
* * LED BO 160 32 1 Yes
162 Failure: Current Summation (Fail-
ure Σ I)
Measurem.Superv OUT On
Off
* * LED BO 135 182 1 Yes
163 Failure: Current Balance (Fail I
balance)
Measurem.Superv OUT On
Off
* * LED BO 135 183 1 Yes
175 Failure: Phase Sequence Current
(Fail Ph. Seq. I)
Measurem.Superv OUT On
Off
* * LED BO 135 191 1 Yes
177 Failure: Battery empty (Fail Bat-
tery)
Device, General OUT On
Off
**LEDBO
178 I/O-Board Error (I/O-Board error) Device, General OUT On
Off
**LEDBO
181 Error: A/D converter (Error A/D-
conv.)
Device, General OUT On
Off
**LEDBO
183 Error Board 1 (Error Board 1) Device, General OUT On
Off
**LEDBO
184 Error Board 2 (Error Board 2) Device, General OUT On
Off
**LEDBO
185 Error Board 3 (Error Board 3) Device, General OUT On
Off
**LEDBO
186 Error Board 4 (Error Board 4) Device, General OUT On
Off
**LEDBO
187 Error Board 5 (Error Board 5) Device, General OUT On
Off
**LEDBO
188 Error Board 6 (Error Board 6) Device, General OUT On
Off
**LEDBO
189 Error Board 7 (Error Board 7) Device, General OUT On
Of
f
**LEDBO
191 Error: Offset (Error Offset) Device, General OUT On
Off
**LEDBO
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
