Siemens SIPROTEC 7SJ61 - Page 431

Appendix
A.9 Information List
SIPROTEC, 7SJ61, Manual
C53000-G1140-C210-1, Release date 02.2008
431
14221 Fail: RTD12 (broken wire/short-
ed) (Fail: RTD12)
RTD-Box OUT On
Off
**LEDBO
14222 RTD12 Temperature stage 1
picked up (RTD12 St.1 p.up)
RTD-Box OUT On
Off
**LEDBO
14223 RTD12 Temperature stage 2
picked up (RTD12 St.2 p.up)
RTD-Box OUT On
Off
**LEDBO
16001 Sum Current Exponentiation Ph
A to Ir^x (ΣI^x A=)
Statistics VI
16002 Sum Current Exponentiation Ph
B to Ir^x (ΣI^x B=)
Statistics VI
16003 Sum Current Exponentiation Ph
C to Ir^x (ΣI^x C=)
Statistics VI
16005 Threshold Sum Curr. Exponent.
exceeded (Threshold ΣI^x>)
SetPoint(Stat) OUT On
Off
**LEDBO
16006 Residual Endurance Phase A
(Resid.Endu. A=)
Statistics VI
16007 Residual Endurance Phase B
(Resid.Endu. B=)
Statistics VI
16008 Residual Endurance Phase C
(Resid.Endu. C=)
Statistics VI
16010 Dropped below Threshold CB
Res.Endurance (Thresh.R.En-
du.<)
SetPoint(Stat) OUT On
Off
**LEDBO
16011 Number of mechanical Trips
Phase A (mechan.TRIP A=)
Statistics VI
16012 Number of mechanical Trips
Phase B (mechan.TRIP B=)
Statistics VI
16013 Number of mechanical Trips
Phase C (mechan.TRIP C=)
Statistics VI
16014 Sum Squared Current Integral
Phase A (ΣI^2t A=)
Statistics VI
16015 Sum Squared Current Integral
Phase B (ΣI^2t B=)
Statistics VI
16016 Sum Squared Current Integral
Phase C (ΣI^2t C=)
Statistics VI
16018 Threshold Sum Squa. Curr. Int.
exceeded (Thresh. ΣI^2t>)
SetPoint(Stat) OUT On
Off
**LEDBO
16019 >52 Breaker Wear Start Criteria
(>52 Wear start)
P.System Data 2 SP On
Off
**LEDBIBO
16020 52 Wear blocked by Time Setting
Failure (52 WearSet.fail)
P.System Data 2 OUT On
Off
**LEDBO
16027 52 Breaker Wear Logic blk Ir-
CB>=Isc-CB (52WL.blk I PErr)
P.System Data 2 OUT On
Off
**LEDBO
16028 52 Breaker W.Log.blk
SwCyc.Isc>=SwCyc.Ir (52WL.blk
n PErr)
P.System Data 2 OUT On
Off
**
LEDBO
16029 Sens.gnd.flt. 51Ns BLOCKED
Setting Error (51Ns BLK PaErr)
Sens. Gnd Fault OUT On
Off
**LEDBO
30053 Fault recording is running (Fault
rec. run.)
Osc. Fault Rec. OUT * * * LED BO
31000 Q0 operationcounter= (Q0
OpCnt=)
Control Device VI *
31001 Q1 operationcounter= (Q1
OpCnt=)
Control Device VI *
31002 Q2 operationcounter= (Q2
OpCnt=)
Control Device VI *
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
