You can find more information about using PROFINET here:
SIMATIC PCS 7 with PROFINET
Device master data files are required for configuring the PSU8600 power supplies
with the SIMATIC manager. The installation files can be downloaded from the
following entry:
GSD for SITOP PSU8600 for integration in STEP 7 V5.5
After the installation of the GSD, the following devices in the hardware catalog are
available:
Table 2-2
Device
Description

Regulated power supply DC 24V / 40A / 4x 10A with PN/IE
connection, web server integrated, OPC UA server
integrated,


Regulated power supply DC 24V / 20A / 4x 5A with PN/IE
connection, web server integrated, OPC UA server
integrated, firmware V1.1...1.4
PSU8600 3ph 40A PN V1.1  1.4
Regulated power supply DC 24V / 20A with PN/IE
connection, integrated web server, integrated OPC UA
server,

PSU8600 3ph 20A PN V1.1  1.4
Regulated power supply DC 24V / 20A with PN/IE
connection, integrated web server, integrated OPC UA
server,

CNX8600 8x2,5A
Expansion module, firmware V1.3 and 1.4
CNX8600 4x5A

CNX8600 4x10A

BUF8600 100ms/40A

BUF8600 300ms/40A

BUF8600 4s/40A

BUF8600 10s/40A

UPS8600
USV module, Firmware V1.4
BAT8600 LiFePO4
Battery module, 48V / 264Wh, maintenance-free lithium iron
phosphate batteries, firmware V1.4
BAT8600 Pb
Battery module, 48V / 380Wh, maintenance-free lead
accumulators, firmware V1.4
