Integration of a SITOP 24V power supply in PCS 7
Entry ID: 10948108, V3.2, 01/2019
8.1 Setting up the hardware configuration
You configure the AS and the external peripherals according to the PCS 7
standard. To configure the power supply system, the corresponding GSD must be
installed.
You can find the Generic Station Description (GSD) in the item entitled "GSD for
SITOP PSU8600 for integration in STEP 7 V5" at the following link:
https://support.industry.siemens.com/cs/ww/en/view/102254061
Parameterizing Ethernet nodes
The SITOP PSU8600 communicates by means of PROFINET IO on the
you have not already done so, you must first adapt
the IP address and the device name of both power supply units to the network
configuration of the field bus.
To parameterize the Ethernet nodes, they must be on the same physical network
as the ES. After this, you can make the separation between the plant bus and
the process bus (field level).
