Integration of a SITOP 24V power supply in PCS 7
Entry ID: 10948108, V3.2, 01/2019
9.2.3 Monitoring of the DC USV
In the sample project, another process picture is configured for monitoring the
uninterruptible power supply. You can call up the picture by switching to the
"SITOP Buffering" sub-area.
Figure 9-6
In the process picture, you get the following information:
• Status of the UPS when connected to Industrial Ethernet (1)
• Status of the UPS when monitoring the signal contacts (2)
Figure 9-7
The block icons of the digital inputs for monitoring the signal contacts of the DC
UPS come from the PCS 7 Advanced Process Library and are not gone into in any
further detail here.
