Siemens SITOP PSE200U

6 Selective monitoring of 24V feeders
Integration of a SITOP 24V power supply in PCS 7
Entry ID: 10948108, V3.2, 01/2019
54
 Siemens AG
2019 All rights reserved
Figure 6-10
2
3
4
Note
In the example, additional color areas have been configured that symbolically
represent the state of the module as LED lamps. In the color areas, the
background color is dynamized and linked to the process value of the monitoring
blocks.
