Configuring the hardware
Proceed as follows:
1. Drag the two identical PSU8600 from the device catalog (1) onto the
PROFINET IO system of the AS. Note that only devices with a 24V output can
be used.
2. Open the properties of both PSUs in succession and enter the device name (2)
and parameterize the IP address (3) of the devices.
Figure 8-3
1
3
2
