Weighing Functions
SIWAREX FTA
5-92
5.15 DR 22 Scale Parameter 1 (AWI)
The weighing parameters that change more often in the process are defined in DR
22. Normally, these parameters are changed for switching materials and are then
sent to the SIWAREX FTA again.
Procedure:
o Define all parameters according to the material properties
o Send DR 22 to the scale
o If required, check parameters using tests
Name
Type
Address
Default
Range of Values / Explanation
Reference
Scale parameter 1
Maximum weighing time
Time
DBD000
0
0: deactivated, Definition in msec.
5.15.1
Trailing weight
REAL
DBD004
1
Wizzard
WB
nmax
*
0,01
Trailing amount after switching fine signal off
5.15.2
Fine weight
REAL
DBD008
20
Wizzard:
WB
nmax
*0,2
Amount for dosing during the fine signal
5.15.3
Shut-off correction value
REAL
DBD012
0
+/- value for moving the shut-off point for the
fine signal
5.15.4
Timer pre-dosing
TIME
DBD016
0
0: deactivated
> 0: Pre-dosing time in msec
5.15.5
TO1
REAL
DBD020
0,2
Wizzard:
WB
nmax
*
0,002
Upper tolerance limit TO1 (entry of the
permitted positive deviation from set weight)
5.15.6
TU1
REAL
DBD024
0,2
Wizzard:
WB
nmax
*
0,002
Lower tolerance limit TU1 (entry of the
permitted negative deviation from set weight)
5.15.6
TO2
REAL
DBB028
0,5
Wizzard:
WB
nmax
*
0,005
Entry of the upper tolerance limit 2, must be
greater than TO1.
5.15.6
TU2
REAL
DBB032
0,5
Wizzard:
WB
nmax
*
0,005
Entry of the lower tolerance limit 2, must be
greater than TU1.
5.15.6
36
Table 5-14 DR 20 Allocation
5.15.1 DR 22 - Maximum Weighing Time
The weighing time is started with the start of a weighing procedure. After the
defined time has elapsed, a test is performed to determine whether the weighing
procedure will take longer. If yes then a technology error “Weighing time exceeded”
is generated. The weighing procedure is not influenced by the technology error
message.
