Weighing Functions
SIWAREX FTA
5-115
Name
Type
Address
Range of Values / Explanation
Reference
Reserved
BYTE
DBB047
Reserved
Impedance reference
value
INT
DBB048
Measured impedance value for load cells [0.1Ω]
Impedance value INT
DBB050
Current impedance value for load cells [0.1Ω]
52
Table 5-21 DR 31 Allocation
5.20.1 DR 31 - Through-put per second
The momentary through-put value in weight units per second.
5.20.2 DR 31 - Current trailing weight
The trailing weight that is being used.
5.20.3 DR 31 - Current fine weight
The fine weight that SIWAREX FTA is using at the moment.
5.20.4 DR 31 - Unfiltered ADC value
The value of the analog/digital converter at the moment - not filtered.
5.20.5 DR 31 - Filtered ADC value after the signal filter
The value of the analog/digital converter at the moment - after filtering in signal
filter (DR3).
5.20.6 DR 31 - Filtered ADC value after the dosing filter
The value of the analog/digital converter at the moment - after filtering in dosing
filter (DR).
5.20.7 DR 31 - Current set value in load operation
The momentary value for the set value in load operation.
5.21 DR 32 Statistic data (AWI)
The statistic data provides information on weighing quality. Creating statistic data is
restarted with the “Delete statistic data” command and will carry on until the next
time that it is deleted.
Residual weighing and the results of dosing in AWI gravimetric filling operating
mode during which a dosing fault occurred are not included in the statistics.
