Accessories
SIWAREX FTA
13 Accessories
There are necessary and optional accessories for the SIWAREX FTA.
The required accessories are indicated in the following table.
Description Order No.
Calibration weighing electronics for automatic weighing instruments for S7-300
and ET200M.
EU Type Certification 3 x 6000d
Application areas: Fast dosing, filling / bagging and emptying.
Attention: Pay attention to certification conditions for calibrating applications.
7MH4900-2AA01
• SIWAREX FTA Manual
(The device manual is only available electronically and may be downloaded
from www.siwarex.com)
SIWAREX FTA Project Planning Package for SIMATIC S7 on CD-ROM
• SETUP for S7- Integration Step7 and TIA-Portal
• Getting Started (S7 classic and TIA-Portal)
• PC parameter software SIWATOOL FTA
• Manual on CD-ROM
• Quick Guides
7MH4900-2AK02
SIWAREX FTA Project Planning Package for PCS7 V6.0 on CD-ROM
• SETUP for S7- Integration
• Getting started
• PC parameter software SIWATOOL FTA
• Manual on CD-ROM
7MH4900-2AK61
STEP 7-Software for SIWAREX FTA.
Control of one or more scales for an expandable number of components and an
optional number of recipes.
Applications. Batch systems, mixing in production processes, CD-ROM
7MH4900-2AL01
STEP 7-Software for SIWAREX FTA.
Control for filling and bagging operations for one or more filling stations and an
optional number of materials, CD-ROM
7MH4900-2AM01
SIWATOOL connection cable from SIWAREX FTA with a serial PC interface,
for 9 pin PC interfaces (RS 232)
• Length 2 m
7MH4702-8CA
• Length 5 m
7MH4702-8CB
• 40-pin front connector
with screw contacts (required for every SIWAREX assembly), alternatively
with spring-clamps - see next point
6ES7 392-1AM00-0AA00
• 40-pin front connector
with spring-clamps (required for every SIWAREX assembly), alternatively
6ES7 392-1BM00-0AA00
