Weighing Functions
SIWAREX FTA
5-61
5.4 DR 4 Basis parameter (NAWI, AWI)
The base parameters determine further features of a scale which are responsible
for its basic behaviour. The parameters must be checked and changed if
necessary.
During calibration operation it is only possible to switch within a group with the
same weighing operating mode.
Procedure:
o Check all parameters and change if necessary.
o Send DR 4 to the scale
Name
Type
Address
Default
Range of Values / Explanation
Reference
Operating mode / Logs
0
Type
BYTE
DBB000
3
Wizzard –
Direct
definition
0 - weighing (additiv) (see 5.4.2)
1 - weighing (subtractiv) (see 5.4.3)
2 - filling (additive) and emptying (see 5.4.4)
3 - filling (additive) without emptying 5.4.5)
4 - filling (subtractive) without emptying (see
5.4.6)
5 - check weight (see 5.4.7)
6 - discontinuous totalizing (see 5.4.8)
7 - filling (additive)./(Big-bag) (see 5.4.9)
8 - filling (subtractiv)/(Big-bag) (see 5.4.10)
9 – filling (subtractive) and emptying (see
5.4.11)
Other definitions are not permitted.
5.4.1
Reserve 1
BYTE
DBB001
0
Reserve 1 (default, must not be changed)
Reserve 2
WORD
DBW002
0
Reserve 2
Monitoring time for
recording
TIME
DBD04
2000
Time within which, a recording task must be
ended (msec)
5.5.8
Device for log output
BYTE
DBB008
1
Bit 0 :
0 = Log output to RS232 interface
1 = Log output to MMC
Bits 1 to 7 not used
5.5.10
Reserve 3
BYTE
DBB009
0
Reserve 3
Limit values
Basis weight for limit
value 1
Basis weight for limit
value 2
Basis weight for
monitoring the empty
range
BYTE
DBB010
0
0
0
Bit 0 :
0 = Basis for limit value 1 is the gross weight
1 = Basis for limit value 1 is the net weight
Bit1 :
0 = Basis for limit value 2 is the gross weight
1 = Basis for limit value 2 is the net weight
Bit 3 :
0: Basis for empty range is the gross weight
1: Basis for empty range is the net weight
Bits 4 to 7 not used
5.5.11
5.5.12
5.5.13
Reserve 4
BYTE
DBB011
0
Reserve 4
