Weighing Functions
SIWAREX FTA
5-114
5.19.12 DR 30 - Totalising memory 2
The momentary value in totalising memory 2 (numeral step from DR3).
5.20 DR 31 Process values 2 (NAWI, AWI)
The current states and data in the scale can be monitored using process values 1
and 2.
Observing the selected data is very helpful in test operation for optimising
parameters. In addition, if the SIWAREX FTA is controlled by the SIMATIC CPU
then the status can also be observed.
Name
Type
Address
Range of Values / Explanation
Reference
Process values extended
Through-put / sec
REAL
DBD000
Actual through-put (amount per second)
Current trailing weight
REAL
DBD004
Current trailing weight
(initialised with default upon receipt of the filling
parameter)
Current fine weight
REAL
DBD008
Current fine weight
(initialised with default upon receipt of the filling
parameter)
Unfiltered ADC value
DINT
DBW012
Direct value from the analog/digital converter,
unfiltered.
Filtered ADC value after
filter 1
DINT
DBW016
Direct value from the analog/digital converter,
after filter 1 (DR3).
Filtered ADC value after
filter 2
DINT
DBW020
Direct value from the analog/digital converter,
after filter 2 (DR23).
Remaining amount to be
filled
REAL
DBD024
Current remaining amount in loading operation
Current set value in load
operation
REAL
DBD028
Actual set weight of an individual weighing
procedures in filling operation.
Operating error bit coded
DWORD
DBB032
Current status of the 32 operating errors (faults).
Date / Time
DATE_AN
D_TIME
DBD036
Actual date and time in SIWAREX in SIMATIC
format.
Current temperature
INT
DBB044
Current temperature °C
Digital input states
BYTE
DBB046
Current status of the digital inputs
Status of digital load cell
BYTE
DBB047
Status of sensor Mettler Toledy type WM or
WMH, the following applies:
Bit 0: Overload
Bit 1: Underload
Bit 2: Unknown instruction (not used with
Wipotec or PESA)
Bit 3: Instruction cannot be executed (not used
with Wipotec or PESA)
Bit 4: Standstill
Bit 5: HW fault
Bit 6: -
Bit 7: Communication fault
