Weighing Functions
SIWAREX FTA
5.2 DR3 Adjustment Parameter (NAWI, AWI)
The adjustment parameter must be tested for every weighing procedure and
changed if necessary.
The scale is basically defined using the adjustment parameters and by performing
the adjustments. In calibration operation, the data of the DR3 cannot be changed
after the calibration is complete.
Procedure:
o Check all parameters and change if necessary.
o Send DR3 to the scale
o Perform scale adjustment
o Receive DR3 from the scale
Name Type Address Default Range of Values / Explanation
Adjustment zero 0
Other definitions not permitted.
Adjustment weight 1
Other definitions not permitted.
Adjustment weight 2
Other definitions not permitted.
Adjustment weight 3
Other definitions not permitted.
Adjustment weight 4
Other definitions not permitted.
> 0
Other definitions not permitted.
> 0
Other definitions not permitted.
> 0
Other definitions not permitted.
> 0
Other definitions not permitted.
range
1: Characteristic value to 1mV/V
2: Characteristic value to 2mV/V
4: Characteristic value to 4mV/V
Other definitions not permitted.
0: Averaging filter before digital filter
1: Digital filter before averaging filter
1: Bessel-Filter
2: Butterworth Filter
Other definitions not permitted.
1: fg = 20Hz
2: fg = 10Hz
3: fg = 5Hz
4: fg = 2Hz
5: fg = 1Hz
6: fg = 0,5Hz
