Siemens SIWAREX FTA - Page 55

Weighing Functions
SIWAREX FTA
5-43
Name Type Address Default Range of Values / Explanation
Re-
ference
8: fg = 0,1Hz
9: fg = 0,05Hz
Other definitions not permitted.
Depth of
averaging filter
WORD
DBW040
10
0 ... 250
0: Averaging filter deactivated
Other definitions not permitted.
5.2.6
Scale name
STRING
[10]
DBB042
“SIWAREX
XX”
5.2.7
Number of weight ranges
BYTE
DBB054
1
1 Range
2 Ranges
3 Ranges
Other definitions not permitted.
5.2.8
Scale type
Zero setting activated at
start-up
Activated zero setting at
start-up, if scale is tared
Automatic zero
adjustment
Tare selection
(subtractive, additive)
BYTE
DBB055
0
0
0
0
0
Bit 0::
0: Multi-range scale
1: Multi-resolution scale
Bit 1 :
0: Switch-on zero setting device switched off;
1: Switch-on zero setting device switched on
Bit 2 :
0: Switch-on zero setting, not when tare ≠ 0
1: Switch-on zero setting, when tare ≠ 0
Bit 3 :
0: Zero tracking device switched off;
1: Zero tracking device switched on
Bit 4:
0: Use a subtractive tare device
1: Use an additive tare device
Bit 5 - 7 not set
5.2.9
5.2.10
5.2.11
5.2.12
5.2.13
Min. weight for
Weighing range 1
REAL
DBD056
1
5.2.14
Max. weight for weighing
range 1
REAL
DBD060
100
5.2.15
Numeral step for
weighing range 1
REAL
DBD064
0,02
Numeral step weighing range 1 (1*10
k
, 2*10
k
, 5*10
k
)
Other definitions not permitted.
5.2.16
Min. weight for
Weighing range 2
REAL
DBD068
0
5.2.17
Maximum weight for
weighing range 2
REAL
DBD072
0
5.2.18
Numeral step for
weighing range 2
REAL
DBD076
0
Numeral step weighing range 2 (1*10
k
, 2*10
k
, 5*10
k
)
Other definitions not permitted.
5.2.19
Min. weight for
Weighing range 3
REAL
DBD080
0
5.2.20
Maximum weight for
weighing range 3
REAL
DBD084
0
5.2.21
Numeral step for
weighing range 3
REAL
DBD088
0
Numeral step weighing range 3 (1*10
k
, 2*10
k
, 5*10
k
)
Other definitions not permitted.
5.2.22
Stand-still time 1
TIME
DBB092
1000sec
msec
5.2.23
Stand-still range 1
REAL
DBD096
0,02
Stand-still range 1 in weight unit
