Weighing Functions
SIWAREX FTA
5-44
Name Type Address Default Range of Values / Explanation
Re-
ference
Max. waiting time for
stand-still 1
TIME
DBB100
2000
If there is no stand-still 1, the respective weighing
instruction will be rejected with an operational error
with a setting of 0 and otherwise, the waiting time
will elapse. If the max. waiting time has elapsed and
there is still no stand-still, an error message is sent.
For weighing instructions that are activated by an
operator, a setting around 2000 ms is reasonable.
(During the weighing cycle, this time is not
monitored)
5.2.25
Max. negative weight for
zero setting when
switching on
BYTE
DBB104
10
Negative range for Switch-on zero setting device [in
% of weighing range
max
]
(Entry of Pos- + Neg. zero set value must not
exceed 20% with country code “OIML”)
5.2.26
Max. positive weight for
zero setting when
switching on
BYTE
DBB105
10
Positive range for Switch-on zero setting device [in
% of weighing range
max
]
(Entry of Pos- + Neg. zero set value must not
exceed 20% with country code “OIML”)
5.2.27
Maximum negative
weight for zero setting
BYTE
DBB106
1
Negative range for zero setting device [in % of
weighing range
max
]
(Entry of Pos- + Neg. zero set value must not
exceed 4% with country code “OIML”)
5.2.28
Maximum positive weight
for zero setting
BYTE
DBB107
3
Negative range for zero setting device [in % of
weighing range
max
]
(Entry of Pos- + Neg. zero set value must not
exceed 4% with country code “OIML”)
5.2.29
Tare max. weight T-
BYTE
DBB108
100
Subtractive tare device range
[in % of WR
max
with multi-range scale]
[in % of WR
1
with multi-resolution scale]
(Value must not exceed 100%)
Range of the additive tare device
[in % of WB
1
, only a single range scale is permitted
in conjunction with regulation code “OIML”]
(Value must not exceed 250%)
5.2.30
Load cell type
BYTE
DBB109
0
0: analog load cell
1: METTLER TOLEDO type WM or WMH
2: WIPOTEC digital load cell
3: PESA digital load cell
>3: analog load cell
5.2.31
Timeout digital LC
WORD
DBW110
240
Timeout in ms for receiving the cyclic weight value
of the digital load cell
5.2.32
Regulations
STRING
[4]
DBB112
“----”
“OIML” : = Regulation Code OIML
“----“: = No Regulation Code
5.2.33
Unit of measurement
STRING
[4]
DBB118
kg
5.2.34
Stand-still range 2
REAL
DBD124
0,02
Stand-still range 2 cm weight unit Effective when
starting a weighing procedure
5.2.35
Stand-still time 2
TIME
DBB128
1000
msec
5.2.36
Max. waiting time for
stand-still 2
TIME
DBB132
500
Max. waiting time for stand-still when starting a
weighing (ms)
0: No waiting time active
5.2.37
Stand-still range 3
REAL
DBD136
0,02
Stand-still range 3 cm weight unit Effective after
switching off fine current.
5.2.38
Stand-still time 3
TIME
DBB140
1000
msec
5.2.39
Minimum waiting time at
stand-still 3
TIME
DBB144
500
Minimum waiting time at stand-still after switching
off fine signal (msec)
0 No waiting time active
5.2.40
Smallest set weight ∑min
REAL
DBD148
100
Wizzard:
= WB
max
Must only be entered with AWI totalizing operating
mode.
5.2.41
Distribution value dt
REAL
DBD152
0,1
dt can correspond with the numerical step in WB
nmax
5.2.42
