Siemens SIWAREX FTA - DR 4 - Scale Operating Mode (Scale Type)

Weighing Functions
SIWAREX FTA
5-62
Name
Type
Address
Default
Range of Values / Explanation
Reference
Empty range
REAL
DBD012
1
Wizzard:
WB
max
*0,01
For filling procedures this depends on
parameters, for emptying procedures relative to
gross
5.5.14
Start-up weight limit
value 1
REAL
DBD016
1
Wizzard:
WB
max
*0,01
5.5.15
Shut-down weight limit
value 1
REAL
DBD020
1,1
Wizzard:
WB
max
*0,01
1
5.5.16
Start-up weight limit
value 2
REAL
DBB024
50
Wizzard:
WB
max
*0,5
5.5.17
Shut-down weight limit
value 2
REAL
DBB028
49
Wizzard:
WB
max
*0,49
5.5.18
Start-up weight limit
value 3
REAL
DBB032
99
Wizzard:
WB
max
*0,99
Limit value 3 corresponds with overfill limit
5.5.19
Shut-down weight limit
value 3
REAL
DBB036
98
Wizzard:
WB
max
*0,98
5.5.20
Through-put
Minimum through-put
Limit value 1
REAL
DBB040
0
0: No monitoring
> 0 minimum through-put [1/sec]
5.5.21
Minimum through-put
Limit value 2
REAL
DBB044
0
0: No monitoring
> 0 minimum through-put [1/sec]
5.5.22
Filter depth of
average value filter for
through-put calculation
BYTE
DBB048
5
[0...255] X 10 msec
5.5.23
Reserve 5
BYTE
DBB049
0
Reserve 5
50
Table 5-2 DR4 Allocation
5.4.1 DR 4 - Scale operating mode (Scale type)
This parameter is used to select the suitable weighing instrument program. One
of these weighing operating modes applies depending on the task description.
5.4.2 DR 4 - Type: weighing (additive)
Non-automatic weighing instrument – according to OIML R-76 – only accepts
service and adjustment commands and “zero setting” and “taring” weighing
instructions. The net weight increases with increasing load on the scale. No dosing
functions are supported.
5.4.3 DR 4 - Type: weighing (subtractive)
Non-automatic weighing instrument – according to OIML R-76 – only accepts
service and adjustment commands and “zero setting” and “taring” weighing
instructions. The net weight increases with decreasing load on the scale.
No dosing functions are supported.
