Weighing Functions
SIWAREX FTA
5-86
Bit 2 defines which memory is used for recording the trace data.
0: Trace data is stored in RAM
1: Trace data is stored in the MMC
The trace function is described in 5.6.29
5.6.27 DR 7 - Memory segment for trace function
The MMC memory can be used for recording the trace data and for recording the
calibratable scale logs.
The percentage of MMC memory that is available for the trace function is defined
with this parameter.
Up to 100% is permitted in this definition but the total for trace function and
calibratable log may not exceed 100%
The trace function is described in 5.6.29
5.6.28 DR 7 - Memory segment for log
The MMC memory can be used for recording the trace data and for recording the
calibratable scale logs.
The percentage of MMC memory that is available for the calibratable logs is
defined with this parameter.
Up to 100% is permitted in this definition but the total for trace function and
calibratable log may not exceed 100%
The trace function is described in 5.6.29
5.6.29 DR 7 - Trace function recording cycle
Every n-te measurement (n x 10 msec) is recorded. When recording to RAM, n ≥ 1
is possible and when recording to MMC, n ≥ 5 is possible.
The recording can be started with the “Start Recording” 70 command and stopped
with “End recording” 71 command.
A recording element has a length of 64 bytes and contains several measurement
values and status bits.
Name
Type
Length
Range of Values / Explanation
Timestamp1
DATE&TIME
8
AWI status
ULONG
4
status bit
NAWI-Status
ULONG
4
status bit
Unfiltered raw value
ULONG
4
Unfiltered digit value from ADC
Filtered raw value
LONG
4
Filtered digit value
Net_Process
FLOAT
4
Net weight
Gross_Process
FLOAT
4
Gross weight
Filtered raw value 2
LONG
4
Filtered digit value from filter level 2
