Weighing Functions
SIWAREX FTA
5-110
Name
Type
Length
Default
Range of Values / Meaning
Preset tare BOOL
1
0 1 if tare memory is occupied with ext. preset value
and has been activated.
Reserve 1
UCHAR
1
0
Reserve 1
Reserve 2
UCHAR
1
0
Reserve 2
Diverse internal states
UCHAR
1
0
Bit 0 stand-alone operation
0 = SIMATIC operation activated
1 = Stand-alone operation activated
Bit 1 recording from dig. Load cell
0 = Recording stopped
1 = Recording activated
Bits 2 to 7 unused
Tara_Prozess
REAL
4
0
Current tare weight process value
Tare average value REAL
4
0 Current tare-average value (when taring with
average value)
Zero set value REAL
4
0 Zero set value (is set during boot if ‚Switch-on zero
setting‘ is activated)
Zero set value
REAL
4
0
Zero set value (is set with zero setting)
Zero value (automatic
correction)
REAL
4
0 Zero point correction value, which is influenced by
the automatic zero adjustment
Impedance reference
value
USHORT
2
0 Impedance reference value
Impedance value USHORT
2
0 Current impedance value from the last
measurement
Slave pointer weight
LONG
4
0
Last largest weight value
operating time ULONG
4
0 Load counter for the operating minutes since the
last default value
Maximum temperature SHORT
2
0 Load previous maximum inner temperature since
last default value [0.1°C] If no temperature value
exists: -100.0°C.
Signal level
INT
2
0
Signal level at measurement input
Checksum
USHORT
2
****
42
Table 5-17 DR 26 Allocation
5.18 DR 27 Internal process value 2 (AWI)
Other current internal states and data can be read in the scale using process value
2 (only with SIWATOOL FTA). Their meanings are directly related to the internal
processing in the firmware cannot always be interpreted from an operator's
viewpoint.
Observing selected data can be helpful during servicing however, for understanding
the behavior of the system. DR 27 cannot be sent to the SIWAREX FTA.
