Hardware Planning and Assembly

SIWAREX FTA

4-36

4.5.14 PC Connection for SIWATOOL FTA

Table RS 232 Interface

Termination Clamp Signal Remark

9 pin D-

type

RS 232 Interface

Table 4-12 PC Connection

Cables are provided for connecting the PC (see Accessories)

Image 4-17 PC Connection
