5.24 DR39 Version recognition SecureOCX
On a legal for trade display, the contents of DR39 must be identical with the
version of the SecureOCX that was used in the WinCC flexible configuration.
Defining the version is done during commissioning.
The SecureOCX for ProTool for national certification can be operated with version
identifier V 0.0.
Name
Type
Length
Default
Range of Values / Meaning
Version recognition
Main designation version
number
STRING[1]
3
V
“V” for product version
Reserved
BYTE
1
0
Primary version number
INT
2
2
Serial number 0..15
Secondary version
number
INT
2
1
Serial number 0..15
8
Table 5-26 DR 39 Allocation
5.25 DR 40 to 43 Log text 1 to 4 (NAWI, AWI)
The logs can be defined in data records DR40 to DR 43. A log text can either be
printed automatically or on command or it can be saved in the calibratable MMC
memory.
Log text entries 1 to 4 are composed of fixed segments such as title and label and
of variable fields.
The variable fields can contain various values from the SIWAREX FTA.
Control characters that will not be printed can be defined in the log for the printer,
e.g. for ESC, the following entry is made:
\E1b whereby \E is the lead-in sequence and 1b is the hexadecimal value for ESC.
In addition, 4 designation variables can be defined in addition to the process
variables. These designations are 4*16 bytes long and can be specified at any time
by the SIMATIC CPU. DR 40 to 43 cannot be defined through the SIMATIC CPU.
Name
Type
Address
Default
Range of Values / Explanation
Reference
Log text 1
Log text 1
STRING[160]
DBB000
LF,’FF0C’,SP,’FF0D’,
SP,’FF0F’,SP,SP,’FF
05’,CR,EOT;
(Prot.-ID, Date, Time,
Weight)
Place holder for field functions
“OFFh,Index” (here shown with ƒxx
.
Unused characters are initialised with 0
(for possible process values see below)
162
Table 5-27 DR 40 Allocation
