Messages and Diagnostics
SIWAREX FTA
7-151
7.7 Message list Technology messages
Error
No.
Technology message - description
Solution
1-10
MMC error
1
Card function not executable
MMC defect or non-existent. MMC check
required.
This error is generated:
 If a trace entry should be made on the
MMC but no formatted MMC is available.
 If the MMC is deleted while a log-/trace
entry is being made.
 If after inserting the MMC, it contains data
errors that cannot be restored.
2
Trace recording aborted since the MMC
is full
The trace recording was aborted since no
further memory is available. If this recording is
defined on the MMC, insert a new MMC. Set
the method of recording before formatting the
MMC so that the oldest data is automatically
overwritten by the new data.
If record to RAM is set then read the data, if
desired, and delete the trace memory. Set the
method of recording if you want to
automatically overwrite the oldest data.
3
Recording aborted since the parameters
have been changed
Trace-recording aborted since the recording
device was redefined during the recording
procedure.
4
Automatic logging not possible since the
MMC is full
Logging to MMC cannot be performed since
there is no more memory left on the MMC.
Insert a new MMC.
5
MMC error
The defined cycle for the trace recording
cannot be processed. There could be
problems with the MMC. Insert a new MMC.
If the problem still occurs, decrease the
recording cycle of the trace function in DR7 or
record to the RAM memory (MMC parameter
in DR 7).
6
The protocol ID requested in D46 could
not be read
Reading the MMC protocol ID requested in
DR46 (S7 interface) could not be performed
successfully.
7
Reserved
8
Reserved
9
Reserved
10
Reserved
11-20
Log output error
11
Log error
Logging the used text is not possible because
a non-defined code for a variable field has
been defined.
Check the log texts in DR40,
41, 42 or 43.
