Commissioning using a PC – SIWATOOL FTA
SIWAREX FTA
All parameters can be changed in online operation. A message window shows the
current contents of the message buffer from SIWAREX FTA. The current process
values can be observed in various windows. For testing purposes, all commands
can be sent to the SIWAREX FTA.
Differences between the online/offline data are marked in red by the SIWATOOL -
both the data record in question and the individual parameter.
For archiving, all data can be read and stored in a file or can be printed.
Warning
In online operation, all data in the module can be edited. The changes are not
automatically fed into the respective scales-data records. You, as the user, must
decide whether the data adjustment is necessary and whether it should be
performed or not.
Image 10-1 SIWATOOL FTA Window Distribution
