Hardware Planning and Assembly

SIWAREX FTA

4-28

Termination Clamp Signal Remark

X1.15 DO 5 Parameter definable function

X1.16 DO 6 Parameter definable function

X1.17 DO 7 Parameter definable function

X1.18 DO 8 Parameter definable function

X1.19 3L+ 24 V for digital outputs

X1.20 3M Ground for digital outputs

Table 4-6 Digital output connections

Image 4-11 Digital outputs
